CloudNativePG Recipe 2 - Inspecting Default Resources in a CloudNativePG Cluster · Unleashing the Power of Postgres in Kubernetes

Table of Contents

Dive into the nitty-gritty of how CloudNativePG works its magic with PostgreSQL cluster stuff, zooming in on configmaps and secrets. Peek behind the curtain of the default Private Key Infrastructure – the secret sauce for stress-free mutual TLS authentication. Get to know the default user and database setups, all decked out for maximum security. This article is your go-to roadmap, cruising through CloudNativePG’s resource wizardry and dishing out real-world tips for a breeze in deploying and handling PostgreSQL clusters.

In my previous recipe, I provided a step-by-step guide on setting up a local playground for CloudNativePG.

In this second recipe, let’s delve into a first group of resources that CloudNativePG automatically configures alongside your requested PostgreSQL cluster. These resources play a crucial role in supporting the implementation of the microservice database paradigm.

I’ll assume that you’ve installed the cluster-example PostgreSQL cluster on your local kind Kubernetes cluster (as explained in Recipe #1), and you’ve also set up the cnpg plugin for kubectl.

Default ConfigMaps #

Let’s start by examining the ConfigMap resources installed by CloudNativePG for a PostgreSQL Cluster:

kubectl get configmaps

This command should produce a similar output:

NAME                      DATA   AGE
cnpg-default-monitoring   1      14h

Focus on the cnpg-default-monitoring ConfigMap, which CloudNativePG installs by default. This ConfigMap contains built-in metrics for the embedded Prometheus exporter. Inspect its content using:

kubectl get -o yaml configmaps cnpg-default-monitoring | less

By default, CloudNativePG associates this ConfigMap in the cluster resource. Verify this by running:

kubectl get cluster cluster-example \
  -o jsonpath="{.spec.monitoring}"  | jq -C

Pay attention to the monitoring section in the returned JSON object:

{
  "customQueriesConfigMap": [
    {
      "key": "queries",
      "name": "cnpg-default-monitoring"
    }
  ],
  "disableDefaultQueries": false,
  "enablePodMonitor": false
}

For more details on the observability framework available in CloudNativePG, including creating custom metrics, refer to the “Monitoring” section in the documentation.

Default Secrets #

Now, let’s explore the core aspects – secrets. Run the following command:

kubectl get secrets

You should see:

NAME                          TYPE                       DATA   AGE
cluster-example-app           kubernetes.io/basic-auth   9      14h
cluster-example-ca            Opaque                     2      14h
cluster-example-replication   kubernetes.io/tls          2      14h
cluster-example-server        kubernetes.io/tls          2      14h

Let’s briefly discuss each:

cluster-example-app: secret containing information about the app user in the PostgreSQL cluster, including credentials
cluster-example-ca: secret containing the Certification Authority (CA) used by the operator for emitting TLS certificates
cluster-example-replication: secret with the TLS client certificate for streaming replication in the HA cluster
cluster-example-server: secret with the TLS certificate of the PostgreSQL server

Understanding the `app` User Secret #

The cluster-example-app secret, classified as kubernetes.io/basic-auth, holds essential details about the app user within the PostgreSQL cluster. This user acts as the owner of the app database, a topic we’ll explore further in this section. The information encapsulated in this secret covers the username, password, Postgres password file, connection string, and more. As common, each piece of information is encoded in base64, aligning with standard secret resource practices.

To gain insights into the contents of the cluster-example-app secret, use the following command:

kubectl describe secret cluster-example-app

For instance, let’s inspect the password file prepared for the app user by executing the following command:

kubectl get secret cluster-example-app \
  -o jsonpath="{.data.pgpass}" | base64 -d

In a disposable environment, this command might return something like:

cluster-example-rw:5432:app:app:<password>

Understanding this output is crucial as it empowers us to mount this secret as a project volume within a container and access the password file from inside the container. By doing so, we can utilize the sensitive information securely without exposing any passwords. This practice enhances security and is particularly valuable in containerized environments.

Feel free to replicate the above process for any field within the secret, including the password. Enjoy exploring and leveraging the power of securely managing sensitive information in your projects!

Secrets for Private Key Infrastructure (PKI) and Transport Layer Security (TLS) #

One of the pillars of CloudNativePG is the secure-by-default posture, the results of years of practicing of the “shift-left on security” DevOps capability.

CloudNativePG by default creates a CA for the cluster, and uses it to emit the TLS certificate for each Postgres server in the HA cluster and implement mutual TLS with client applications.

Let’s inspect for example the CA certificate with in the cluster-example-ca secret:

kubectl get secret cluster-example-ca \
  -o jsonpath="{.data['ca\.crt']}" | \
  base64 -d | \
  openssl x509 -text -noout

This will return:

Certificate:
    Data:
        Version: 3 (0x2)
        Serial Number:
            d2:a1:0f:48:4b:c4:33:38:72:f9:64:cf:d9:b0:56:e5
        Signature Algorithm: ecdsa-with-SHA256
        Issuer: OU=default, CN=cluster-example
        Validity
            Not Before: Mar  7 17:09:44 2024 GMT
            Not After : Jun  5 17:09:44 2024 GMT
        Subject: OU=default, CN=cluster-example
        Subject Public Key Info:
            Public Key Algorithm: id-ecPublicKey
                Public-Key: (256 bit)
                pub:
                    04:a0:5a:da:e4:3e:bb:c7:3a:39:4e:9c:02:a7:d2:
                    05:bd:68:07:06:f2:2f:94:d2:92:59:be:5f:15:9c:
                    24:06:a0:87:ff:1b:1d:b7:0d:ff:ad:ef:da:98:e3:
                    04:bb:e0:06:93:f8:64:5e:1d:d0:52:77:a5:68:7d:
                    f8:26:e8:c2:57
                ASN1 OID: prime256v1
                NIST CURVE: P-256
        X509v3 extensions:
            X509v3 Key Usage: critical
                Certificate Sign
            X509v3 Basic Constraints: critical
                CA:TRUE
            X509v3 Subject Key Identifier:
                33:0F:04:43:ED:4C:8D:B0:39:57:50:67:8F:04:C6:CE:57:31:9C:6A
    Signature Algorithm: ecdsa-with-SHA256
    Signature Value:
        30:45:02:20:1c:e4:8e:43:d4:02:74:df:09:1d:36:0d:18:b0:
        dc:26:2f:6d:75:2b:ae:01:42:e3:be:80:0e:b2:cf:01:09:5b:
        02:21:00:c5:31:75:85:26:98:9e:76:e7:ea:5f:ad:b8:02:b9:
        bf:8b:0c:2c:dc:01:7e:25:e7:15:d7:7c:01:5e:0d:c0:14

This CA certificate is used by CloudNativePG to sign the PostgreSQL server certificate, stored in the cluster-example-server secret. Try:

kubectl get secret cluster-example-server \
  -o jsonpath="{.data['tls\.crt']}" | \
  base64 -d | \
  openssl x509 -text -noout

Look at the returned certificate, paying specific attention to the Subject and X509v3 Subject Alternative Name sections:

Certificate:
    Data:
        Version: 3 (0x2)
        Serial Number:
            79:89:0e:55:f5:d8:ea:0e:62:85:b0:b5:b3:91:22:b6
        Signature Algorithm: ecdsa-with-SHA256
        Issuer: OU=default, CN=cluster-example
        Validity
            Not Before: Mar  7 17:09:44 2024 GMT
            Not After : Jun  5 17:09:44 2024 GMT
        Subject: CN=cluster-example-rw
        Subject Public Key Info:
            Public Key Algorithm: id-ecPublicKey
                Public-Key: (256 bit)
                pub:
                    04:5f:2f:3e:f7:dc:d3:f0:1b:06:e5:6e:a5:96:cb:
                    ba:74:06:69:d3:5f:17:d6:56:29:df:aa:54:da:e8:
                    6a:5a:45:a7:45:c8:78:92:8a:fb:f5:df:d2:4a:1c:
                    7b:b6:77:00:95:ff:8a:14:bd:6b:dc:a3:6b:69:00:
                    51:3e:9c:e1:c7
                ASN1 OID: prime256v1
                NIST CURVE: P-256
        X509v3 extensions:
            X509v3 Key Usage: critical
                Digital Signature, Key Encipherment, Key Agreement
            X509v3 Extended Key Usage:
                TLS Web Server Authentication
            X509v3 Basic Constraints: critical
                CA:FALSE
            X509v3 Authority Key Identifier:
                33:0F:04:43:ED:4C:8D:B0:39:57:50:67:8F:04:C6:CE:57:31:9C:6A
            X509v3 Subject Alternative Name:
                DNS:cluster-example-rw, DNS:cluster-example-rw.default, DNS:cluster-example-rw.default.svc, DNS:cluster-example-r, DNS:cluster-example-r.default, DNS:cluster-example-r.default.svc, DNS:cluster-example-ro, DNS:cluster-example-ro.default, DNS:cluster-example-ro.default.svc, DNS:cluster-example-rw
    Signature Algorithm: ecdsa-with-SHA256
    Signature Value:
        30:46:02:21:00:ee:69:23:35:23:af:2c:ca:da:6a:af:c7:90:
        60:40:35:70:d8:5b:3f:91:88:31:bc:17:65:35:db:b4:b8:52:
        c4:02:21:00:93:30:96:ce:4b:49:6b:ff:a0:83:cf:6b:91:2d:
        e0:5d:33:17:42:d6:3d:02:24:94:7f:fa:3d:e0:c2:04:0d:6b

The X509v3 Subject Alternative Name section contains all the alternative names of any Kubernetes service automatically created for the cluster.

Besides the certificate, the above secrets also contain the private key, enabling the operator to self-sign the client certificates, starting from the one used for streaming replication.

The TLS certificate for streaming replication #

The last certificate is cluster-example-replication, containing the certificate for the streaming_replica user in PostgreSQL. Run:

kubectl get secret cluster-example-replication \
  -o jsonpath="{.data['tls\.crt']}" | \
  base64 -d | \
  openssl x509 -text -noout

You can spot the Postgres user name from the Subject field below:

Certificate:
    Data:
        Version: 3 (0x2)
        Serial Number:
            f2:69:76:c2:74:41:0c:a6:ca:be:f9:99:eb:3e:9b:78
        Signature Algorithm: ecdsa-with-SHA256
        Issuer: OU=default, CN=cluster-example
        Validity
            Not Before: Mar  7 17:09:44 2024 GMT
            Not After : Jun  5 17:09:44 2024 GMT
        Subject: CN=streaming_replica
        Subject Public Key Info:
            Public Key Algorithm: id-ecPublicKey
                Public-Key: (256 bit)
                pub:
                    04:87:06:92:01:10:07:d3:2d:10:6b:6e:27:4b:1a:
                    c3:f5:b4:c2:25:a4:d6:77:f4:a2:d3:d2:22:47:fe:
                    68:60:1d:a6:19:7a:ed:e2:30:f1:d5:8d:c6:ca:67:
                    81:ca:20:50:48:63:7e:b3:e2:16:a1:79:4d:f5:36:
                    d0:2c:c4:f2:d5
                ASN1 OID: prime256v1
                NIST CURVE: P-256
        X509v3 extensions:
            X509v3 Key Usage: critical
                Digital Signature, Key Agreement
            X509v3 Extended Key Usage:
                TLS Web Client Authentication
            X509v3 Basic Constraints: critical
                CA:FALSE
            X509v3 Authority Key Identifier:
                33:0F:04:43:ED:4C:8D:B0:39:57:50:67:8F:04:C6:CE:57:31:9C:6A
    Signature Algorithm: ecdsa-with-SHA256
    Signature Value:
        30:44:02:20:71:7e:62:67:62:c2:82:ea:c7:9b:49:2e:59:90:
        a3:8b:8a:a9:a2:51:6c:fd:18:ff:99:0e:fb:1e:81:12:df:6b:
        02:20:35:ea:a0:ff:8c:a7:15:b4:79:a3:51:9f:b0:28:ce:40:
        b0:42:3c:3c:81:65:7d:16:3e:16:a9:0a:8d:b6:d2:c8

The feature we’ve incorporated into CloudNativePG as the default behavior is somewhat uncommon with PostgreSQL outside the Kubernetes ecosystem. This rarity is attributed to the inherent complexity of managing certificates, a challenge mitigated by Kubernetes, where certificates serve as a foundational element. Moreover, by default, CloudNativePG systematically rotates these certificates every 90 days.

For those familiar with PostgreSQL, the instantaneous configuration of the primary_conninfo setting for mutual TLS authentication (sans password) on the initial replica in the cluster is a noteworthy occurrence. Verify this behavior firsthand by executing the following command:

kubectl exec -ti -c postgres cluster-example-2 \
  -- psql -qAt -c 'SHOW primary_conninfo'

This will produce output similar to the following:

host=cluster-example-rw
user=streaming_replica
port=5432
sslkey=/controller/certificates/streaming_replica.key
sslcert=/controller/certificates/streaming_replica.crt
sslrootcert=/controller/certificates/server-ca.crt
application_name=cluster-example-2
sslmode=verify-ca

If the security provided by self-signed certificates isn’t sufficient for your needs, you have the flexibility to integrate CloudNativePG with external certificate solutions such as cert-manager, thereby enhancing security and encryption in your PostgreSQL deployments.

Default global objects in PostgreSQL #

By default, CloudNativePG establishes the following:

The streaming_replica user, as previously discussed
An application user named app
An application database named app

To inspect the users, execute the following command:

kubectl exec -ti -c postgres cluster-example-1 -- psql -c '\du'

This command produces the following output:

                                 List of roles
     Role name     |                         Attributes
-------------------+------------------------------------------------------------
 app               |
 postgres          | Superuser, Create role, Create DB, Replication, Bypass RLS
 streaming_replica | Replication

Likewise, to view the databases, use:

kubectl exec -ti -c postgres cluster-example-1 -- psql -c '\l'

As illustrated, in addition to the default databases generated by PostgreSQL (postgres, template0, and template1), CloudNativePG introduces the app database, with ownership assigned to the app user.

                                                  List of databases
   Name    |  Owner   | Encoding | Locale Provider | Collate | Ctype | ICU Locale | ICU Rules |   Access privileges
-----------+----------+----------+-----------------+---------+-------+------------+-----------+-----------------------
 app       | app      | UTF8     | libc            | C       | C     |            |           |
 postgres  | postgres | UTF8     | libc            | C       | C     |            |           |
 template0 | postgres | UTF8     | libc            | C       | C     |            |           | =c/postgres          +
           |          |          |                 |         |       |            |           | postgres=CTc/postgres
 template1 | postgres | UTF8     | libc            | C       | C     |            |           | =c/postgres          +
           |          |          |                 |         |       |            |           | postgres=CTc/postgres
(4 rows)

Conclusions #

This “One Cluster = One Database” approach embodies what I term the microservice database paradigm. Embracing this model involves housing a single database within a cluster. Rather than consolidating multiple databases within a single Postgres cluster, the recommendation is to create distinct clusters, each dedicated to a microservice database. Detailed insights into this strategy are available in our FAQ section.

In this framework, the specifics of the database, such as its name and the owning user (app), become less significant. The focal point shifts to the identity of the cluster itself, as the namespace:name pair is unique in the entire Kubernetes cluster.

That wraps up today’s discussion. We’ve covered substantial ground, and in the upcoming recipes, I’ll delve further into our microservice database recommendation and elucidate the default setup automatically orchestrated by CloudNativePG through the principle of convention over configuration.
