CloudNativePG Recipe 9 - Inspecting the network and the storage in a CloudNativePG cluster
![](https://www.gabrielebartolini.it/articles/2024/07/cloudnativepg-recipe-9-inspecting-the-network-and-the-storage-in-a-cloudnativepg-cluster/cover_hue46edda20bc1cb11c163415928851cb9_334388_660x0_resize_q75_box.jpg)
In this blog post, I delve into the crucial aspects of networking and storage within a CloudNativePG cluster deployed on Kubernetes. I explore how Kubernetes services manage external and internal communications for PostgreSQL clusters, ensuring high availability and seamless failover. Additionally, I examine the role of PersistentVolumeClaims in handling PostgreSQL data storage, offering insights into effective resource management. This article provides an example of the kind of knowledge DBAs need to acquire when managing PostgreSQL in cloud-native environments, highlighting the importance of collaboration with infrastructure teams and developers to ensure robust and resilient cluster operations.
In this article, I will cover two key resources essential for a CloudNativePG cluster deployed in Kubernetes: networking and storage.
Networking is crucial for external communication between a PostgreSQL cluster and applications, as well as for internal communication between PostgreSQL instances for high availability (HA). Storage is a fundamental requirement for any database, ensuring data persistence and reliability.
These concepts are also vital for database administrators (DBAs) transitioning
to Kubernetes. Networking surrounds our PostgreSQL cluster, while storage lies
beneath it. Understanding these aspects enables DBAs to collaborate effectively
with infrastructure and platform engineers, as well as developers, particularly
when managing Cluster
resources.
IMPORTANT: This article requires the local playground covered in CNPG Recipe #1. For a broader understanding, I recommend also going through Recipes #2 and #3.
Let’s connect to your local Kubernetes cluster in kind
and check the list of
PostgreSQL clusters:
kubectl get clusters
Returning:
NAME AGE INSTANCES READY STATUS PRIMARY
cluster-example 86s 3 3 Cluster in healthy state cluster-example-1
The cluster-example
cluster comprises three instances, a primary
(cluster-example-1
) and two standby instances (cluster-example-2
and
cluster-example-3
). Each instance runs in a separate pod, as shown with the
following command:
kubectl get pods
Returning:
NAME READY STATUS RESTARTS AGE
cluster-example-1 1/1 Running 0 81s
cluster-example-2 1/1 Running 0 61s
cluster-example-3 1/1 Running 0 43s
CloudNativePG is responsible for the PostgreSQL cluster resource and leverages
the Kubernetes API for both networking (using the Service
resource) and
storage (via the PersistentVolumeClaim
and, indirectly, StorageClass
resources) without reinventing the wheel. Kubernetes coordinates all these
components, trusting the CloudNativePG controller to manage these resources and
converge the observed state of a Postgres cluster to the desired one. This
makes an operator special when managing a database workload like Postgres.
Let’s now start with the networking side.
Networking #
Kubernetes provides a standard resource called Service
,
an abstraction that enables exposing a group of pods over a network. In the
context of CloudNativePG, this service exposes the PostgreSQL TCP service (port
5432) of each instance running in a pod, allowing applications to connect
seamlessly.
The first question that comes to mind is: “How can I connect to the primary?”
CloudNativePG abstracts the complexity of PostgreSQL’s primary/standby
architecture by providing a service that always points to the primary instance.
This eliminates the need for applications to know the specific pod name where
the primary runs. Each cluster includes a mandatory Service
object, named
after the cluster with the -rw
suffix, of type ClusterIP
, which points to
the IP of the pod running the primary.
The second question that comes to mind is: “What happens if the primary goes down?”
CloudNativePG’s controller ensures that in the event of a primary failure, the service promptly points to the new primary by using its selector, which relies on pod labels to identify the target. CloudNativePG correctly sets these labels on the pods (and on storage, as we’ll discuss later) to first remove the link to the former primary and then, after promotion, point to the new leader. This automated failover mechanism provides high availability and self-healing capabilities. This approach treats PostgreSQL databases more like cattle than pets, although I advocate for a middle ground where PostgreSQL instances are treated more specially than cattle but not quite as uniquely as pets—hence my motto: cattle vs. pets (vs. elephants).
Additionally, the service ensures the correct routing during routine maintenance tasks such as updates, configuration changes, and switchovers.
Furthermore, CloudNativePG automatically creates a -ro
service, which points
to any available hot standby instances (replicas accepting read-only
transactions) for read-only queries, and a -r
service, which points to any
available instance. Version 1.24 introduces support for the
.spec.managed.services.disabledDefaultServices
option, allowing us to skip
the generation of these two default services.
By managing these services, the operator provides a robust and resilient PostgreSQL environment that adheres to Cloud Native principles. This allows developers to focus on building and maintaining their applications without worrying about the underlying database infrastructure.
To view the services managed by the operator, use the following command:
kubectl get services
This command will list all the Kubernetes services associated with your CloudNativePG cluster, giving you an overview of the available resources:
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
cluster-example-r ClusterIP 10.96.69.243 <none> 5432/TCP 93s
cluster-example-ro ClusterIP 10.96.194.161 <none> 5432/TCP 93s
cluster-example-rw ClusterIP 10.96.239.81 <none> 5432/TCP 93s
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 5m
Let’s examine the cluster-example-rw
service in more detail with:
kubectl describe service cluster-example-rw
Returning:
Name: cluster-example-rw
Namespace: default
Labels: cnpg.io/cluster=cluster-example
Annotations: cnpg.io/operatorVersion: 1.23.2
Selector: cnpg.io/cluster=cluster-example,role=primary
Type: ClusterIP
IP Family Policy: SingleStack
IP Families: IPv4
IP: 10.96.239.81
IPs: 10.96.239.81
Port: postgres 5432/TCP
TargetPort: 5432/TCP
Endpoints: 10.244.0.20:5432
Session Affinity: None
Events: <none>
Pay attention to the Selector
field, which identifies the primary pod of the
cluster-example
cluster. Ultimately though, the most relevant information is in the
Endpoints
section, which shows a single entry: TCP port 5432 on host
10.244.0.20. Let’s retrieve the IPs of our pods:
kubectl get pods -o wide
Returning:
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
cluster-example-1 1/1 Running 0 7m52s 10.244.0.20 cnpg-control-plane <none> <none>
cluster-example-2 1/1 Running 0 7m32s 10.244.0.23 cnpg-control-plane <none> <none>
cluster-example-3 1/1 Running 0 7m14s 10.244.0.26 cnpg-control-plane <none> <none>
As you can see, 10.244.0.20
is the IP address of the cluster-example-1
pod,
which runs the primary PostgreSQL instance.
If you describe the cluster-example-ro
service, you will see two endpoints:
10.244.0.23:5432
and 10.244.0.26:5432
.
This automation leverages the concept of Kubernetes’ service selectors in Kubernetes, eliminating the need to manually coordinate changes with Virtual IPs, DNS entries, and connection poolers. It significantly simplifies management and reduces the risk of errors, including split-brain scenarios where different cluster instances mistakenly assume they are the primary.
Another useful command is:
kubectl get endpoints
Returning all the endpoints:
NAME ENDPOINTS AGE
cluster-example-r 10.244.0.20:5432,10.244.0.23:5432,10.244.0.26:5432 10m
cluster-example-ro 10.244.0.23:5432,10.244.0.26:5432 10m
cluster-example-rw 10.244.0.20:5432 10m
kubernetes 172.18.0.2:6443 15m
Storage #
CloudNativePG directly manages PostgreSQL files. In the simplest scenario, it
handles a single volume containing the PGDATA
directory, where all PostgreSQL
data files are stored. Additionally, you can separate Write-Ahead Log (WAL)
files into a different volume and manage PostgreSQL tablespaces as separate
volumes.
PostgreSQL volumes are instantiated through a
standard Kubernetes resource called PersistentVolumeClaim
(PVC),
which defines the request for persistent storage for a pod. Let’s list the PVCs
in our example:
kubectl get pvc
Returning:
NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE
cluster-example-1 Bound pvc-5ecd8058-84a5-456b-8498-24ea5283c9bd 1Gi RWO standard 11m
cluster-example-2 Bound pvc-485f6e81-63c4-428f-ac34-3f6b557665a7 1Gi RWO standard 11m
cluster-example-3 Bound pvc-6a94ce46-43e2-4741-bd19-e117019f16f5 1Gi RWO standard 11m
Next, let’s get more information about the PVC of the first pod by running:
kubectl describe pvc cluster-example-1
We should expect an output similar to the following:
Name: cluster-example-1
Namespace: default
StorageClass: standard
Status: Bound
Volume: pvc-5ecd8058-84a5-456b-8498-24ea5283c9bd
Labels: cnpg.io/cluster=cluster-example
cnpg.io/instanceName=cluster-example-1
cnpg.io/instanceRole=primary
cnpg.io/pvcRole=PG_DATA
role=primary
Annotations: cnpg.io/nodeSerial: 1
cnpg.io/operatorVersion: 1.23.2
cnpg.io/pvcStatus: ready
pv.kubernetes.io/bind-completed: yes
pv.kubernetes.io/bound-by-controller: yes
volume.beta.kubernetes.io/storage-provisioner: rancher.io/local-path
volume.kubernetes.io/selected-node: cnpg-control-plane
volume.kubernetes.io/storage-provisioner: rancher.io/local-path
Finalizers: [kubernetes.io/pvc-protection]
Capacity: 1Gi
Access Modes: RWO
VolumeMode: Filesystem
Used By: cluster-example-1
Events: <none>
Key information includes:
Storage Class: The default storage class (
standard
in our environment) is used because none was specified in the.spec.storage
stanza. You can check this by running:kubectl get storageclass
Returning:
NAME PROVISIONER RECLAIMPOLICY VOLUMEBINDINGMODE ALLOWVOLUMEEXPANSION AGE standard (default) rancher.io/local-path Delete WaitForFirstConsumer false 16m
Volume: The name of the persistent volume associated with the PVC and subsequently with the
cluster-example-1
pod (seeUsed By
).Labels and Annotations: Starting with
cnpg.io
, these are controlled and managed by CloudNativePG (e.g.,cnpg.io/pvcRole=PG_DATA
indicates that the volume contains thePGDATA
).Volume Mode: Set to
Filesystem
, meaning the volume is mounted as a directory in the file system of the pod.Access Mode: Set to
ReadWriteOnce
(RWO).Capacity: The size of the volume.
If you are curious, you can get more information about the underlying storage
class or the persistent volumes using the kubectl describe storageclass standard
and kubectl describe pv cluster-example-1
commands.
Conclusions #
To summarise, a PostgreSQL Cluster
resource sits between applications and the
storage, with networking seamlessly enabling secure connections with the
database. CloudNativePG uses standard Kubernetes resources, facilitating
conversations between infrastructure teams and DBAs/developers who are
responsible for a PostgreSQL cluster.
DBAs operating in a multidisciplinary development team don’t need to master the
entire Kubernetes ecosystem. They only need to learn enough Kubernetes to
manage PostgreSQL Cluster
objects effectively, thus enabling them to
participate in intelligent conversations with their counterparts — from
planning the architecture and storage (day 0) to managing production
environments (day 2).
In this article, I covered networking, including the read-only service that enables distributing reads on a replica through PostgreSQL hot standby capability, and storage, focusing on persistent volume claims. Take time to familiarise yourself with these resources, conduct your research, and experiment. This will enhance your knowledge and improve the overall performance of PostgreSQL in Kubernetes.
Stay tuned for the upcoming recipes! For the latest updates, consider subscribing to my LinkedIn and Twitter channels.
