CloudNativePG Recipe 11 - Isolating PostgreSQL Workloads in Kubernetes with Kind

·8 mins
Fault tolerance GitOps pipelines high availability Infrastructure as Code IaC Kubernetes control plane Kubernetes scheduling Kubernetes nodes Multi-node cluster Node labels Node taints Node selectors PostgreSQL clustering Pod anti-affinity Production environment simulation Scheduling Workload isolation cloudnativepg cluster cnpg ci/cd pipelines cloudnative databases database cluster data on kubernetes developer productivity deployment automation docker dok e2e testing kubernetes k8s kind kubectl operator postgresql postgres
Table of Contents

In modern Kubernetes environments, isolating PostgreSQL workloads is crucial for ensuring stability, security, and performance. This article, building on the previous CNPG Recipe #10, explores advanced techniques for isolating PostgreSQL instances using Kubernetes with Kind. By applying taints, labels, and anti-affinity rules, you can ensure that PostgreSQL nodes are dedicated exclusively to database workloads, preventing overlap with other services and enhancing fault tolerance. Whether you’re simulating a production environment or managing a live deployment, these strategies will help you maintain a robust and isolated PostgreSQL cluster in Kubernetes.

In CNPG Recipe #10, I demonstrated how to set up a local Kind cluster with dedicated PostgreSQL nodes using Kubernetes node labels and CloudNativePG node selectors for scheduling. Specifically, I proposed using the node-role.kubernetes.io/postgres label to designate nodes exclusively for PostgreSQL workloads.

While node labels and selectors help direct PostgreSQL workloads to specific nodes, they do not fully isolate these workloads, which can lead to overlap with other services or instances.

In this article, I will cover:

  • Ensuring that PostgreSQL nodes exclusively run PostgreSQL workloads.
  • Preventing multiple PostgreSQL instances within the same cluster from being scheduled on the same node.

To achieve better isolation, I propose using the node-role.kubernetes.io/postgres taint, ensuring that PostgreSQL nodes are dedicated solely to PostgreSQL workloads.

Before You Start #

Please review CNPG Recipe #10 before diving into this recipe, as it provides essential foundational knowledge and setup necessary for this guide.

Tainting Our Multi-Node Cluster #

We will build on the multi-node cluster set up in CNPG Recipe #10.

Our focus here is on applying a taint to each PostgreSQL node, ensuring that only pods with the necessary tolerations can be scheduled and run on them. Specifically, I propose using the node-role.kubernetes.io/postgres taint, as demonstrated in the following Kind configuration file:

kind: Cluster
apiVersion: kind.x-k8s.io/v1alpha4
name: multi-node-taints-template
nodes:

# Control Plane node
- role: control-plane

# Infrastructure/Application nodes (2)
- role: worker
  labels:
    infra.node.kubernetes.io:
- role: worker
  labels:
    app.node.kubernetes.io:

# PostgreSQL nodes (3)
- role: worker
  labels:
    postgres.node.kubernetes.io:
  kubeadmConfigPatches:
  - |
    kind: JoinConfiguration
    nodeRegistration:
      taints:
      - key: node-role.kubernetes.io/postgres
        effect: NoSchedule
- role: worker
  labels:
    postgres.node.kubernetes.io:
  kubeadmConfigPatches:
  - |
    kind: JoinConfiguration
    nodeRegistration:
      taints:
      - key: node-role.kubernetes.io/postgres
        effect: NoSchedule
- role: worker
  labels:
    postgres.node.kubernetes.io:
  kubeadmConfigPatches:
  - |
    kind: JoinConfiguration
    nodeRegistration:
      taints:
      - key: node-role.kubernetes.io/postgres
        effect: NoSchedule

# Spare node
- role: worker

You’ll also notice an additional node —I’ll explain its purpose later.

To set up your cluster, download the multi-node-taints-template.yaml file and run the following command:

kind create cluster --config multi-node-taints-template.yaml --name cnpg

The output will confirm that your kind cluster is successfully up and running.

Next, assign the appropriate node-role.kubernetes.io/* labels to the nodes:

# Assigning role labels to nodes based on existing labels
kubectl label node -l postgres.node.kubernetes.io node-role.kubernetes.io/postgres=
kubectl label node -l infra.node.kubernetes.io node-role.kubernetes.io/infra=
kubectl label node -l app.node.kubernetes.io node-role.kubernetes.io/app=

After applying these labels, confirm they are correctly set by running:

kubectl get nodes

This will display the nodes and their labels, ensuring they are properly configured:

NAME                 STATUS   ROLES           AGE     VERSION
cnpg-control-plane   Ready    control-plane   5m14s   v1.31.0
cnpg-worker          Ready    infra           5m1s    v1.31.0
cnpg-worker2         Ready    app             5m1s    v1.31.0
cnpg-worker3         Ready    postgres        5m      v1.31.0
cnpg-worker4         Ready    postgres        5m1s    v1.31.0
cnpg-worker5         Ready    postgres        5m1s    v1.31.0
cnpg-worker6         Ready    <none>          5m1s    v1.31.0

To inspect the taints applied to a specific node, use:

kubectl describe node cnpg-worker5 | grep '^Taints'

This will confirm that the cnpg-worker5 node has the postgres taint applied.

You may have also noticed the spare node cnpg-worker6, which we will use later.

Isolating CNPG Clusters on postgres Nodes #

In this recipe, I will focus exclusively on the postgres nodes, deliberately excluding the infra and app nodes.

As outlined earlier, our goal is to create a PostgreSQL cluster using CloudNativePG and ensure the following:

  • PostgreSQL workloads run exclusively on PostgreSQL nodes: This aligns with the primary objective of CNPG Recipe #10.
  • PostgreSQL nodes are dedicated solely to PostgreSQL workloads: This is partially achieved using the node-role.kubernetes.io/postgres:NoSchedule taint, which prevents non-PostgreSQL workloads from being scheduled on these nodes. The use of tolerations on PostgreSQL Cluster resources will fully enforce this isolation.
  • Instances of the same PostgreSQL Cluster are distributed across different nodes: This ensures high availability and fault tolerance by enforcing pod anti-affinity rules, which schedule each instance on a separate node.

All of this is encapsulated in CloudNativePG through the following .spec.affinity configuration:

# <snip>
affinity:
  nodeSelector:
    node-role.kubernetes.io/postgres: ""

  # Set the toleration for the taint
  tolerations:
  - key: node-role.kubernetes.io/postgres
    operator: Exists
    effect: NoSchedule

  # Ensure that instances are scheduled and run on different nodes
  enablePodAntiAffinity: true
  topologyKey: kubernetes.io/hostname
  podAntiAffinityType: required

Let’s Get Started #

First, install the CloudNativePG operator.

In this example, I’ll use the latest development build of CloudNativePG for testing:

curl -sSfL \
  https://raw.githubusercontent.com/cloudnative-pg/artifacts/main/manifests/operator-manifest.yaml | \
  kubectl apply --server-side -f -

Verify that the operator is running:

kubectl get pods -A -o wide

The output should show that the operator is running on a non-Postgres node, confirming that the taints are working.

Next, create the PostgreSQL cluster using the following manifest:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: cluster-example
spec:
  instances: 3

  storage:
    size: 1Gi

  affinity:
    nodeSelector:
      node-role.kubernetes.io/postgres: ""

    # Set the toleration for the taint
    tolerations:
    - key: node-role.kubernetes.io/postgres
      operator: Exists
      effect: NoSchedule

    # Ensure that instances are scheduled and run on different nodes
    enablePodAntiAffinity: true
    topologyKey: kubernetes.io/hostname
    podAntiAffinityType: required

Download the cluster-example.yaml file and deploy it with:

kubectl apply -f cluster-example.yaml

Finally, confirm that PostgreSQL workloads are running on the Postgres nodes by running:

kubectl get pods -o wide

This should show that the PostgreSQL workloads are correctly isolated on the designated Postgres nodes, ensuring that the taints and tolerations are functioning as intended:

NAME                READY   STATUS    RESTARTS   AGE     IP           NODE           NOMINATED NODE   READINESS GATES
cluster-example-1   1/1     Running   0          3m12s   10.244.7.4   cnpg-worker3   <none>           <none>
cluster-example-2   1/1     Running   0          2m34s   10.244.1.4   cnpg-worker5   <none>           <none>
cluster-example-3   1/1     Running   0          113s    10.244.4.4   cnpg-worker4   <none>           <none>

To ensure that no instances of the same PostgreSQL Cluster can be scheduled on the same Postgres node, let’s scale up the cluster to 4 instances:

kubectl scale cluster --replicas 4 cluster-example

If you observe the output of kubectl get pods -w, you’ll see that the fourth instance remains in a pending state. Investigating further with:

kubectl describe pod cluster-example-4

will show that CloudNativePG enforces node selectors, pod anti-affinity rules, and taints/tolerations, preventing any new scheduling due to the lack of available Postgres nodes without an existing instance.

This is the expected behavior and confirms that our setup is working as intended.

What’s Next? #

In real-world scenarios, you would typically choose one of two exit strategies:

  1. Adding a node for PostgreSQL
  2. Scaling back to three instances (rollback)

Adding a New Node for PostgreSQL #

To simulate adding a new node for PostgreSQL, we’ll use the spare node we previously created in the cluster.

First, apply the PostgreSQL taint to the node:

kubectl taint node cnpg-worker6 node-role.kubernetes.io/postgres=:NoSchedule

You can verify the taint was applied correctly by running:

kubectl describe node cnpg-worker6 | grep '^Taints'

The expected output should confirm the taint:

Taints:             node-role.kubernetes.io/postgres:NoSchedule

Next, assign the PostgreSQL node label to cnpg-worker6:

kubectl label node cnpg-worker6 node-role.kubernetes.io/postgres=

This final step will unblock the pending cluster-example-4-join job and successfully create the third replica of cluster-example.

Scaling Back to Three Instances #

If the cluster-example-4-join job is pending, another option is to roll back to the original two-replica PostgreSQL cluster.

To scale back, run:

kubectl scale cluster --replicas 3 cluster-example

Next, manually delete the pending job and its associated PVC:

kubectl delete job cluster-example-4-join
kubectl delete pvc cluster-example-4

This will restore the cluster to a healthy state.

Conclusion #

In this article, we demonstrated how to effectively isolate PostgreSQL workloads within a Kubernetes environment using Kind.

By applying taints, labels, and anti-affinity rules, we directed PostgreSQL workloads to specific nodes while isolating them from non-database workloads. This approach strengthens the security and stability of your database clusters while offering enhanced control over resource allocation.

Additionally, by employing Infrastructure as Code principles, we achieved a clearer separation of responsibilities between database administrators (who manage the Cluster resource, node selectors, tolerations, and pod anti-affinity) and infrastructure administrators (who handle nodes, labels, and taints). This separation streamlines management and fosters collaboration.

I also plan to propose making the node-role.kubernetes.io/postgres labels and taints an official recommendation within the CloudNativePG project, promoting the wider adoption of these best practices across the community.

In keeping with Cloud Native principles, the methods we explored in Kind are fully portable across any Kubernetes-based platform—whether private, public, hybrid, multi-cloud, or managed. This ensures that these strategies can be consistently applied, regardless of the underlying infrastructure.

These techniques are crucial for those looking to simulate production environments or manage PostgreSQL clusters with greater precision. As your deployments grow in complexity, these strategies will be essential for maintaining the performance, integrity, and reliability of your Kubernetes workloads.
