This recipe shows how to perform an online major PostgreSQL upgrade using the new declarative approach to logical replication introduced in CloudNativePG 1.25. By leveraging the Publication and Subscription CRDs, users can set up logical replication between PostgreSQL clusters with ease. I will walk you through configuring a PostgreSQL 15 publisher, importing schemas into a PostgreSQL 17 subscriber, and verifying data synchronisation, with the broader goal of highlighting the benefits of a repeatable and testable upgrade process.

Upgrading PostgreSQL to a major version has historically been one of the most challenging tasks for users. To minimise downtime during the upgrade process, two primary approaches are commonly used:

Offline In-Place Upgrade Using pg_upgrade to ensure that the data files from an older version are converted to the newer version.
Online Remote Upgrade Leveraging native logical replication for minimal downtime. For a detailed guide, check out “CNPG #5 - How to Migrate Your PostgreSQL Database in Kubernetes with ~0 Downtime from Anywhere”, as it covers concepts essential for fully understanding this article.

Although CloudNativePG does not currently support pg_upgrade ( planned for version 1.26), version 1.25 introduces a significant new feature: declarative support for logical publications and subscriptions.

This article demonstrates how to perform an online major PostgreSQL upgrade on your laptop using kind (Kubernetes in Docker). I’ll use the Publication and Subscription CRDs introduced in the preview version 1.25.0-rc1.

Please help us test this release candidate in a non-production environment by following the instructions provided here.

Use Case: Online Major PostgreSQL Upgrade #

Imagine you have a CloudNativePG-managed PostgreSQL 15 database running in your Kubernetes cluster. Your goal is to upgrade it to PostgreSQL 17 while meeting the following requirements:

Repeatability: The process should be repeatable to ensure reliability.
Testability: Run a test migration to provide ample time for developers and testers to validate the upgraded database. This also allows you to measure the time required for data transfer, and practice the cutover procedure.
Production-Readiness: Ensure a fresh migration is performed from scratch before switching to the new database in production. This approach minimises downtime for the application, reducing it to near-zero levels.

Installing CloudNativePG Preview Version 1.25.0 #

Before proceeding, ensure you’ve completed the steps in “CloudNativePG Recipe 1 - Setting Up Your Local Playground in Minutes”. For this example, you’ll need version 1.25 to use the declarative Publication and Subscription CRDs.

To install version 1.25.0-rc1, run the following command:

kubectl apply --server-side -f \
  https://raw.githubusercontent.com/cloudnative-pg/cloudnative-pg/main/releases/cnpg-1.25.0-rc1.yaml

Make sure you also have the latest version of the cnpg plugin for kubectl, as described in CloudNativePG Recipe #1.

Setting Up the Origin Database #

Let’s start by defining a PostgreSQL 15 cluster with the following configuration:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: pg-15
spec:
  instances: 3

  storage:
    size: 1Gi

Populating the Database with Sample Data #

We’ll use pgbench to generate and insert sample data into the database. Run the following command:

kubectl cnpg pgbench \
  --db-name app \
  --job-name pgbench-init \
  pg-15 \
  -- --initialize

After running the command, inspect the job logs to confirm the operation:

kubectl logs jobs/pgbench-init

You should see output similar to the following:

dropping old tables...
NOTICE:  table "pgbench_accounts" does not exist, skipping
NOTICE:  table "pgbench_branches" does not exist, skipping
NOTICE:  table "pgbench_history" does not exist, skipping
NOTICE:  table "pgbench_tellers" does not exist, skipping
creating tables...
generating data (client-side)...
100000 of 100000 tuples (100%) of pgbench_accounts done (elapsed 0.01 s, remaining 0.00 s)
vacuuming...
creating primary keys...
done in 0.16 s (drop tables 0.00 s, create tables 0.01 s, client-side generate 0.07 s, vacuum 0.04 s, primary keys 0.04 s).

At this point, the app database should contain the pgbench tables and be approximately 22 MB in size. You can verify this by running:

kubectl cnpg psql pg-15 -- app -c '\dt+' -c '\l+'

Setting Up the Destination Database #

Next, you’ll define the PostgreSQL 17 cluster and configure it to import the schema from its source, pg-15, which serves as the “publisher” in logical replication terms:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: pg-17
spec:
  instances: 3

  storage:
    size: 1Gi

  # Use the microservice import for the schema
  bootstrap:
    initdb:
      import:
        type: microservice
        schemaOnly: true
        databases:
          - app
        source:
          externalCluster: pg-15

  # Define the "publisher"
  externalClusters:
  - name: pg-15
    connectionParameters:
      host: pg-15-rw.default.svc
      user: app
      dbname: app
    password:
      name: pg-15-app
      key: password

In the example above, the externalClusters section specifies how to connect to the publisher using the app user.

Once the manifest is applied, the destination server will have the schema imported but without any data. You can verify this by running:

kubectl cnpg psql pg-17 -- app -c '\dt+'

You should get a similar output:

                                        List of relations
 Schema |       Name       | Type  | Owner | Persistence | Access method |  Size   | Description
--------+------------------+-------+-------+-------------+---------------+---------+-------------
 public | pgbench_accounts | table | app   | permanent   | heap          | 0 bytes |
 public | pgbench_branches | table | app   | permanent   | heap          | 0 bytes |
 public | pgbench_history  | table | app   | permanent   | heap          | 0 bytes |
 public | pgbench_tellers  | table | app   | permanent   | heap          | 0 bytes |
(4 rows)

Setting Up the Publisher #

The first step in configuring logical replication is enabling a role to be used in a logical publication in the app database. For this example, we’ll use the app user for simplicity. Below, we assign the replication privilege to the app user:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: pg-15
spec:
  instances: 3

  storage:
    size: 1Gi

  managed:
    roles:
      - name: app
        login: true
        replication: true

We then create the Publication resource that will be then used to replicate all changes to all tables in the app database.

apiVersion: postgresql.cnpg.io/v1
kind: Publication
metadata:
  name: pg-15-publisher
spec:
  cluster:
    name: pg-15
  dbname: app
  name: publisher
  target:
    allTables: true
  publicationReclaimPolicy: delete

Apply the manifest and check the app user:

kubectl cnpg psql pg-15 -- app -c '\du app'

      List of roles
 Role name | Attributes
-----------+-------------
 app       | Replication

Setting Up the Subscriber #

With the pg-17 database schema imported, the next step is to configure the subscription to the “publisher” on pg-15. This establishes logical replication between the two clusters:

apiVersion: postgresql.cnpg.io/v1
kind: Subscription
metadata:
  name: pg-17-subscription
spec:
  cluster:
    name: pg-17
  dbname: app
  name: subscriber
  externalClusterName: pg-15
  publicationName: publisher
  subscriptionReclaimPolicy: delete

Apply the manifest to initiate the subscription, then check the logs of both clusters. You should see entries indicating that logical replication has started, such as:

logical replication apply worker for subscription "subscriber" has started

or:

starting logical decoding for slot "subscriber"

Finally, verify that the pgbench_accounts table on the destination database contains 10,000 records by running the following command:

kubectl cnpg psql pg-17 -- app -qAt -c 'SELECT count(*) FROM pgbench_accounts'

Once you have migrated, you can delete the subscription and publication objects.

Conclusions #

This article introduced the basics of setting up logical replication using the new declarative approach in CloudNativePG 1.25. While the focus was on core concepts, there are additional aspects to consider, such as synchronising sequences—which are not part of the pgbench database. Detailed guidance on this topic is available in CNPG Recipe #5 through the use of plugins— this task is still imperative or delegated to the application.

For cutover, transitioning your applications to the new pg-17-rw service will finalise the process. If your publisher resides outside the control of CloudNativePG, you can still benefit from the declarative subscriptions.

The primary goal of this article was to showcase the streamlined and repeatable process for managing PostgreSQL native logical replication through the new declarative method for defining publications and subscriptions. This approach significantly enhances the manageability and efficiency of logical replication in Kubernetes environments.
