CNPG Recipe 17 - PostgreSQL In-Place Major Upgrades

·9 mins
kubernetes k8s cloudnativepg cnpg postgresql postgres dok data on kubernetes
Table of Contents

CloudNativePG 1.26 introduces one of its most anticipated features: declarative in-place major upgrades for PostgreSQL using pg_upgrade. This new approach allows you to upgrade PostgreSQL clusters by simply modifying the imageName in their configuration—just like a minor version update. While it requires brief downtime, it significantly reduces operational overhead, making it ideal for managing large fleets of PostgreSQL databases in Kubernetes. In this article, I will explore how it works, its benefits and limitations, and cover an upgrade of a 2.2TB database.

CloudNativePG 1.26, expected at the end of this month, introduces one of the most highly anticipated features in the project’s history: in-place major version upgrades of PostgreSQL using pg_upgrade.

Unlike minor upgrades, which primarily involve applying patches, major upgrades require handling changes to the internal storage format introduced by the new PostgreSQL version.

This feature is now available for public testing through the preview 1.26.0-rc1 release.

An Overview of the Existing Methods #

CloudNativePG now provides three declarative (yes, declarative!) methods for performing major version upgrades. Two of these require a new cluster and are classified as blue/green deployment strategies.

The first approach leverages the import capability with pg_dump and pg_restore. While practical for small databases and useful for testing new versions, the final cutover requires downtime, making it an offline upgrade.

The second method takes advantage of PostgreSQL’s native logical replication, enabling zero-downtime upgrades—hence, an online upgrade—regardless of database size. This remains my preferred approach for upgrading business-critical PostgreSQL databases. It can also be used for migrations from external environments into Kubernetes (e.g., from Amazon RDS to CloudNativePG). For more details, see “CloudNativePG Recipe 15 - PostgreSQL Major Online Upgrades with Logical Replication”.

The third method, and the focus of this article, is offline in-place upgrades using pg_upgrade, PostgreSQL’s official tool for this kind of operations.

The Use Case for In-Place Major Upgrades #

The primary motivation for introducing this feature in Kubernetes is to eliminate the operational difference between minor and major PostgreSQL upgrades for GitOps users. With this approach, upgrading simply requires modifying the cluster configuration’s spec and updating the image for all cluster components (primary and standby servers). This is particularly beneficial at scale—when managing dozens or even hundreds of PostgreSQL clusters within the same Kubernetes cluster—where blue/green upgrades pose operational challenges.

Before You Start #

In-place major upgrades are currently available for preview and testing in CloudNativePG 1.26.0-RC1. You can test this feature on any Kubernetes cluster, including a local setup using kind, as explained in “CloudNativePG Recipe 1 - Setting Up Your Local Playground in Minutes”.

To deploy CloudNativePG 1.26.0-RC1, run:

kubectl apply --server-side -f \
  https://raw.githubusercontent.com/cloudnative-pg/cloudnative-pg/main/releases/cnpg-1.26.0-rc1.yaml

How It Works #

CloudNativePG allows you to specify the PostgreSQL operand image in two ways:

  • Using the .spec.imageName option
  • Using image catalogs (ImageCatalog and ClusterImageCatalog resources)

This article focuses on the imageName method, though the same principles apply to the image catalog approach.

Let’s assume you have a PostgreSQL cluster running with:

imageName: ghcr.io/cloudnative-pg/postgresql:13.20-minimal-bullseye

This means your cluster is using the latest available container image for PostgreSQL 13 (minor version 20). Since PostgreSQL 13 reaches end-of-life in November this year, you decide to upgrade to PostgreSQL 17 using the ghcr.io/cloudnative-pg/postgresql:17.4-minimal-bullseye image.

By updating the imageName field in the cluster configuration, CloudNativePG automatically initiates a major version upgrade.

The Upgrade Process #

The first step is safely shutting down the PostgreSQL cluster to ensure data consistency before upgrading. This is an offline operation that incurs downtime, but it allows modifications to static data files with full integrity.

CloudNativePG then updates the Cluster resource status to record the currently running image before initiating the upgrade. This is essential for rollback in case of failure (discussed later in the article).

After that, CloudNativePG starts a Kubernetes job responsible for preparing the PostgreSQL data files on the Persistent Volume Claims (PVC) for the new major version using pg_upgrade:

  • The job creates a temporary copy of the old PostgreSQL binaries.
  • It initializes a new PGDATA directory using initdb for the target PostgreSQL version.
  • It verifies the upgrade requirement by comparing the on-disk PostgreSQL versions, preventing unintended upgrades based on image tags.
  • It automatically remaps WAL and tablespace volumes as needed.

At this point, it runs the actual upgrade process with pg_upgrade and the --link option to leverage hard links, significantly speeding up data migration while minimizing storage overhead and disk I/0.

If the upgrade completes successfully, CloudNativePG replaces the original PostgreSQL data directories with the upgraded versions, destroys the persistent volume claims of the replicas, and restarts the cluster.

However, if pg_upgrade encounters an error, you will need to manually revert to the previous PostgreSQL major version by updating the Cluster specification and deleting the upgrade job. Like any in-place upgrade, there is always a risk of failure. To mitigate this, it is crucial to maintain continuous base backups. If your storage class supports volume snapshots, consider taking one before initiating the upgrade—it’s a simple precaution that could save you from unexpected issues.

Overall, this streamlined approach enhances the efficiency and reliability of in-place major upgrades, making PostgreSQL version transitions more manageable in Kubernetes environments.

Example #

The best way to understand this feature is to test it in practice. Let’s start with a basic PostgreSQL 13 cluster named pg, defined in the following pg.yaml:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: pg
spec:
  imageName: ghcr.io/cloudnative-pg/postgresql:13.20-minimal-bullseye
  instances: 3

  storage:
    size: 1Gi
  walStorage:
    size: 1Gi

After creating the cluster, check its status with:

kubectl cnpg status pg

You can also verify the version with psql:

kubectl cnpg psql pg -- -qAt -c 'SELECT version()'

Returning something similar to this:

PostgreSQL 13.20 (Debian 13.20-1.pgdg110+1) on x86_64-pc-linux-gnu, compiled by gcc (Debian 10.2.1-6) 10.2.1 20210110, 64-bit

Now, let’s upgrade from PostgreSQL 13, which is nearing end-of-life, to the latest minor release of the most recent major version. To do this, simply update the imageName field in your configuration:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: pg
spec:
  imageName: ghcr.io/cloudnative-pg/postgresql:17.4-minimal-bullseye
  instances: 3

  storage:
    size: 1Gi
  walStorage:
    size: 1Gi

Apply the changes to trigger the major upgrade procedure:

kubectl apply -f pg.yaml

Once the process is complete, verify the upgrade by checking the cluster status again. Your database should now be running PostgreSQL 17.

If you check again the version, you should now get a similar output:

PostgreSQL 17.4 (Debian 17.4-1.pgdg110+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 10.2.1-6) 10.2.1 20210110, 64-bit

If you type kubectl get pods now, you will see that pods and PVCs named pg-2 and pg-3 don’t exist anymore, as the scale up operation replaced them with sequence numbers 4 and 5:

NAME   READY   STATUS    RESTARTS   AGE
pg-1   1/1     Running   0          62s
pg-4   1/1     Running   0          36s
pg-5   1/1     Running   0          15s

Limitations and Caveats #

As you have just experienced, one limitation of this implementation—though it does not affect database access—is the need to recreate replicas, which is currently supported only via pg_basebackup. This means that until a new replica is available, if the primary node fails, you will need to restore from the most recent backup. In most cases, this backup will be from the previous PostgreSQL version, requiring you to repeat the major upgrade process.

While this scenario is unlikely, it is important to acknowledge the risk. However, in most cases, replication completes within minutes, depending on database complexity (primarily number of tables).

For significantly larger databases, be aware that the cluster will remain in a degraded state for high availability until replication is fully restored. To mitigate risk, I strongly recommend taking a physical backup as soon as possible after the upgrade completes.

Another key consideration is extensions. They are an integral part of the upgrade process. Ensure that all required extensions—and their respective versions—are available in the target PostgreSQL version’s operand image. If any are missing, the upgrade will fail. Always validate extension compatibility before proceeding.

Testing a Large Database Upgrade #

As part of my testing efforts, I wanted to evaluate how a major PostgreSQL upgrade handles a large database. To do this, I created a 2.2TB PostgreSQL 16 database using pgbench with a scale of 150,000. Below is an excerpt from the cnpg status command:

Cluster Summary
Name                 default/pg
System ID:           7487705689911701534
PostgreSQL Image:    ghcr.io/cloudnative-pg/postgresql:16
Primary instance:    pg-1
Primary start time:  2025-03-30 20:42:26 +0000 UTC (uptime 72h32m31s)
Status:              Cluster in healthy state
Instances:           1
Ready instances:     1
Size:                2.2T
Current Write LSN:   1D0/8000000 (Timeline: 1 - WAL File: 00000001000001D000000001)
<snip>

I then triggered an upgrade to PostgreSQL 17, which completed in just 33 seconds, restoring the cluster to full operation in under a minute. Below is the updated cnpg status output:

Cluster Summary
Name                 default/pg
System ID:           7488830276033003555
PostgreSQL Image:    ghcr.io/cloudnative-pg/postgresql:17
Primary instance:    pg-1
Primary start time:  2025-03-30 20:42:26 +0000 UTC (uptime 72h44m45s)
Status:              Cluster in healthy state
Instances:           1
Ready instances:     1
Size:                2.2T
Current Write LSN:   1D0/F404F9E0 (Timeline: 1 - WAL File: 00000001000001D00000003D)

Since CloudNativePG leverages PostgreSQL’s --link option (which uses hard links), upgrade time primarily depends on the number of tables rather than database size.

Conclusions #

In-place major upgrades with pg_upgrade bring PostgreSQL’s traditional upgrade path into Kubernetes, giving users a declarative way to transition between major versions with minimal operational overhead. While this method does involve downtime, it eliminates the need for blue/green clusters, making it particularly well-suited for environments managing a large fleet of small to medium-sized PostgreSQL instances.

If the upgrade succeeds, you have a fully functional PostgreSQL cluster, just as if you had run pg_upgrade on a traditional VM or bare metal instance. If it fails, rollback options are available—including reverting to the original manifest and deleting the upgrade job. If necessary, continuous backups provide an additional safety net.

Although in-place upgrades may not be my preferred method for mission-critical databases, they provide an important option for teams that prioritise operational simplicity and scalability over achieving zero-downtime upgrades. As demonstrated in testing, upgrade times primarily depend on the number of tables rather than database size, making this approach efficient even for large datasets.

The success of this feature relies on real-world feedback. We encourage you to test and validate it during the release candidate phase to ensure CloudNativePG 1.26.0 is robust and production-ready—especially when using extensions. Your insights will directly influence its future, so let us know what you think!
